KMF (E5.2) 06/2014 page 18/99
2.1 Unit overview
Figure 4: KMF 240
(A) Instrument box
(B) Door handle
(C) Outer door
(D) Refrigerating machine and humidity generation module
2.2 Instrument box
(1)
Figure 5: Triangle instrument box
(1) MB1 microprocessor program controller with 2-channel technology for temperature and humidity
(A)
(B)
(C)
(D)
