Biodom C15 - ALARM DIRTY Troubleshooting

Biodom C15 | instructions for use, maintenance and installation | February 2019
53
YES
Is there failure in
flow meter?
Service
NO
YES
Flow through the
burner insufficient?
1. Secure the air intake in the boiler room
2. Check entry point of air into boiler
3. Clean the burner and the chamber beneath
4. Check the doors
5. Check the lid of the container (it has to be
shut!!!)
Replace electronics
(check the FLOW on display: 150-600)
1. If torn or damaged, replace
2. If clogged or squeezed, clean or reinstall
correctly
3. Clean the pipe that connects the white huba
and fire chamber
1. Check voltage output from electronics
2. Check white round safety pressure control
3. Replace the fan
4. Replace electronic
YES
NO
Does the fan 1
works?
YES
NO
Are the silicone
tubes in order?
ALARM DIRTY
Fan 1 reached maximum
speed, but the air flow is
insufficient
