E80/E70 Digital Electrocardiograph User’s Manual
4-14
——Select 【Speed】: Set the paper moving speed of recorder. Optional
speed: 12.5mm/s，25mm/s，50mm/s.
——Select【Gain】: Set the length of ECG 1mV on thermo sensitive chart
paper. Optional gain: 5mm/mV, 10 mm/mV, 20mm/mV, 10/5mm/mV,
20/10mm/mV, Auto. Gain 40mm/mV can optional.
——Select【Paper width】: Set the width of thermo sensitive chart paper.
——Select【Paper type】: Set the type of paper. Optional type: 210mm，
216mm.
After setup of recorder, select【OK】.
Caution:
When the chart paper with calibration mark is in use, the machine
may automatically adjust the starting and ending positions of each
page of record. When the chart paper without calibration mark is in
use, controls over recording position and stop information are not
required at the time of each startup of record export.
Chart paper setup shall be correct completely; otherwise, record will
possibly be wrong.
The USB printer can directly output ECG report when it is in auto
mode.
The optional external USB printer need the support of the printer
language of PCL5 or PCL6.
4.7 Report Info Setup
The users may set the relevant information of recorder. Press“Report
info/F3”in main interface to enter report info setup interface, As shown
following chart:
