E80/E70 Digital Electrocardiograph User’s Manual
5-7
5.2.3 Manual Mode
In manual mode, real-time recording of ECG waveform is conducted
manually according to the requirements of users, and start and stop of
recording are controlled via keys. The figure below shows 12-channel ECG
record report in manual mode.
Fig. 5-7: Manual mode report
A: Patient info (include: name, ID, age and gender)
B: HR
C: The time recording report
D: Waveform info
E: Work mode
F: Baseline drift filter (On) and lowpass filter frequency
G: Gain
H: Speed
A
B
C
D
E
FG
H
I
J
