E80/E70 Digital Electrocardiograph User’s Manual
5-8
I: 1mV calibration signal
J: AC filter status
5.2.4 Rhythm Mode
In Rhythm mode, specific lead rhythm is analyzed. The machine supports
single-rhythm lead mode and 3-rhythm lead mode. In single-rhythm lead
mode, the waveform data of 60s are collected; in 3-rhythm lead mode, the
waveform data of 20s are collected.

single-rhythm lead mode:
Fig. 5-8: single-rhythm lead mode
A
C
D
E
F
G
H
I
B
J
K
