E80/E70 Digital Electrocardiograph User’s Manual
5-9
3-rhythm lead mode:
Fig. 5-9: 3-rhythm lead mode
A: Patient info (include: name, ID, age and gender)
B: HR
C: The time recording report
D: Waveform info
E: Work mode
F: Baseline drift filter (Off) and lowpass filter frequency
G: Gain
H: Speed
I: 1mV calibration signal
J: Time record
K: AC filter status
A
C
B
D
E
F
G
H
I
J
K
