Patient Monitor User’s Manual
6-2
the 5-lead ECG cable. So please plug the 5-lead ECG cable into
the ECG socket and refer to 5.3 Monitoring Procedure to place
the RA and LL leads onto the body of patient.
Warning: For the sake of safety, all the leads on the
5-lead ECG cable must be connected to the
body of patient.
Caution:
In order to get the best Resp waveforms, when
selecting leadⅡfor measuring Resp, it is advised to
place RA and LL electrodes cornerways.
For reducing the influence of rhythmic blood flow on
Resp electrode pickup impedance changes, avoid the
liver area and ventricles of heart in the line between
RA and LL electrodes. This is particularly important
for neonates.
The measurement of RESP is not applicable for
patient with excessive motion, otherwise it may cause
the mistake of RESP alarm.
