Specifications Specifications
TRANSMITTER CHARGER SPECIFICATIONS
Charger Channel 1
Indicator LED (Green/ Amber)
Input Port
Weight
USB Type A
10 g (± 1.0)
Charger Dimensions
Input
Output
Storage Conditions
Operation Conditions
Ingress Protection Rating
37.3 x 26.0 x 22.5 mm (± 0.5 mm)
DC 5V/18 ~ 20 mA
DC 4.2V/18 ~ 20 mA
Temperature: 5°C - 45°C (41°F - 113°F)
Relative humidity: 10% - 90%
Temperature: 5°C - 45°C (41°F - 113°F)
Relative humidity: 10% - 90%
Caution: When operating the transmitter on a tester in air
temperatures greater than 41°C (106°F), the temperature of the
transmitter may exceed 43°C (109°F)
IP21
Protected from touch by fingers and objects greater than 12.5
millimeters. Protected from condensation.
