BionX RIDE+ - Technical Specifications

EN-32
ENGLISH
teChnICal desCrIptIon
6. Technical description
6.1 Bike specifics
Motor
Brushless motor
Maximum continuous power output
250W
Maximum assisted speed
25km/h
Wheel nut torque
40Nm
Max. load bike (rider & luggage)
125kg
Total weight bike (incl. battery pack)
23.4-28.0kg(dependingonmodel)
6.2 Battery packs
RIDE+ R250-2 RIDE+ R320 RIDE+ R420 RIDE+ C420
Voltage
37V 48V 48V 48V
Capacity
6.6Ah 6.6Ah 8.5Ah 8.8Ah
Power
244Wh 317Wh 408Wh 423Wh
Weight
2.4kg 2.8kg 3.8kg 3.8kg
Life
Atleast600full
discharge-charge
cycles
Atleast600full
discharge-
charge cycles
Atleast600full
discharge-charge
cycles
Atleast600full
discharge-charge
cycles
Charging time fully
discharged battery
3to4hours 3to4hours 4to5hours 4to5hours
6.3 Minimum and maximum temperatures for battery pack
Status Min (
o
C) Max (
o
C)
Charging
0 45
Use
-10 50
Storage
5 25
6.4 Power Supply
Input voltage
100VACto240VAC
Input current
1.6A
Output voltage
26VDC
Output current
3.45A
6.5 Compliance
AstandardRIDE+electricbike(Pedelec)isanEPAC(ElectricallyPowerAssistedCycle)incompliance
withEuropeanNormEN15194.
TheRIDE+‘Fastclass’E-bikes(CategoryL1e,onlyallowedinGermany,AustriaandSwitzerland)have
ECtype-approvalwithregardtoDirective2002/24/ECinadditiontocompliancewithEN15194.
