Biosense Webster nGEN - Controls on the Back of the Pump

Page 6
nGEN™ Pump User Manual
9.4 Controls on the Back of the Pump
Table 4 – Controls on the Back of the Pump
1 Device label
2 COMM: socket for the generator connection cable
3 Service access door. Do not open.
4 Potential equalization pin
5 24VDC: socket for the AC adapter
6 Bracket
7 IV pole mounting pin
