Bitzer 2DES-3.F1Y

KT-210-4 21
3 Technical data
Frequency inverter .F1
Operating voltage 380 .. 480 V ±10% 3 phases (three phase current) 50/60 Hz
Required fuse and contactor se-
lection
Required fuse type gG
Recommended: 25A
Maximum: 32A
If the UL/cUL conformity must be adhered to, back-up fuses of the types Buss-
mann KTSR 500 V or Ferraz Shawmut, ATMR, class CC (max. 30 A) must be
used. The fuses must be designed for the protection of a circuit that can supply
max. 100,000 A (symmetrical) at max. 500V.
Compressor (protection device SE-B1) 4A quick acting
The main contactor (K1) connected upstream of the FI must be equipped with
the "safe stop" function, i.e. the entire compressor-FI unit must be de-ener-
gised when the main contactor is switched off.
Inputs and outputs
Data communication Terminal strip X100
• RS485
• Shielded cables recommended.
Control signal cable Terminal strip X101, terminals 1, 2 and 8
• Use shielded cables.
• Terminals 2 and 8: 4..20mA.
• Terminals 2 and 8: 0..10V.
Digital inputs Terminal strip X101, terminals 3 and 6
• Use shielded cables, gold-plated contacts recommended.
• Potential-free contact required. Switching voltage 24 V DC max. 120 mA.
Fault message relay Terminal strip X102
Max. terminal power AC: 250 V AC, 2 A, 500 VA
Max. terminal power DC: 25 V DC, 2 A, 50 W / 50 V DC, 1 A, 50 W
Min. terminal power: 24 V AC, 100 mA, 24 V DC, 10 mA
Potential-free contacts Gold-plated contacts recommended
Compressor protection device SE-B1
Operating voltage 230 V AC +10%/-15%, 50/60 Hz
Other voltages upon request
Neutral conductor required
Connection cables
Power connections (electricity
supply)
Spring-type terminals L1, L2, L3 and terminal screw PE
Connection cable max. 10mm
2
Control connections Plug-in terminal strips X100, X101 and X102
Terminals are suitable for max. 1.5mm
2
(AWG16)
Available cable bushings on the
FI housing
see chapter Dimensional drawings, page 24
