BIXOLON SRP-350plusIII Driver Manual

SRP-350plusIII
Rev. 1.02
- 31 -
5-4-2 2d Barcodes
Windows driver supports two-dimensional barcode type as shown in the following table.
Set the two-dimensional barcode type supported by the Windows driver in the “Barcode
Font Name” field to print the barcode.
Barcode Font Name
Barcode Type
Size (Point)
2D-Code1
PDF417
9.5
2D-Code2
QR Code
9.5
Detailed settings for two-dimensional barcode
Select “Barcode Font Name” and “Barcode Type” of one-dimensional barcode and click
the “Properties” button. Various options such as width, height, size, and error
compensation level can be configured depending on the type of two-dimensional barcode
from this window as shown in the following picture.
<QR Code>
<PDF417>

BIXOLON SRP-350plusIII Specifications

General

Type	POS printer
Character size	24 x 24 mm
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Product color	Gray
Maximum roll diameter	83 mm
Supported paper width	80/58 mm
Maximum printing width	72 mm
Printing media thickness	50 - 80 µm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
USB port	Yes
Serial interface type	RS-232
USB 2.0 ports quantity	1
Connectivity technology	Wired
Wi-Fi	No
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, ITF, ITF-14, ITF-25, Micro QR Code, QR Code, UPC-A, UPC-E
Autocutter durability	1.8 million cuts
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	146 mm
Width	145 mm
Height	204 mm
