BIXOLON SRP-350plusIII Driver Manual

SRP-350plusIII
Rev. 1.02
- 42 -
6-2 “FontControl” Font
This Windows driver supports the special functions as shown in the following table.
Select the “FontControl” character first and use the characters in the table to use the
special functions. Take care as this function is not for printing general texts.
Character
Special Functions
5
Print HT (0 x 09)
6
Print LF (0 x 0A)
7
Print CR (0 x 0D)
a
Open Drawer 2 (50ms driver pulse width)
b
Open Drawer 2 (100ms driver pulse width)
c
Open Drawer 2 (150ms driver pulse width)
d
Open Drawer 2 (200ms driver pulse width)
e
Open Drawer 2 (250ms driver pulse width)
f
Open Drawer 2 without paper feeding (50ms driver pulse width)
g
Cut without paper feeding
i
Prints the NV Image saved in the 00 address (double-size)
j
Prints the NV Image saved in the 01 address (double-size)
k
Prints the NV Image saved in the 02 address (double-size)
l
Prints the NV Image saved in the 03 address (double-size)
m
Prints the NV Image saved in the 04 address (double-size)
p
Do not add HRI characters to barcode
q
Add HRI characters above the bard code with Font A
r
Add HRI characters below the bard code with Font A
s
Add HRI characters above the bard code with Font B
t
Add HRI characters below the bard code with Font B
u
Turns white/black reverse printing mode on
v
Turns white/black reverse printing mode off
w
Align text to the left
x
Align text to the center
y
Align text to the right
A
Open Drawer 1 (50ms driver pulse width)
B
Open Drawer 1 (100ms driver pulse width)
C
Open Drawer 1 (150ms driver pulse width)
D
Open Drawer 1 (200ms driver pulse width)
E
Open Drawer 1 (250ms driver pulse width)
F
Open Drawer 1 without paper feeding (50ms driver pulse width)
G
Prints the NV bitmap image 1
H
Prints the NV bitmap image 2
I
Prints the NV bitmap image 3
J
Prints the NV bitmap image 4
K
Prints the NV bitmap image 5
P
Cut (partial cut)
R
Prints the NV Image saved in the 00 address
S
Prints the NV Image saved in the 01 address
T
Prints the NV Image saved in the 02 address
U
Prints the NV Image saved in the 03 address
V
Prints the NV Image saved in the 04 address
[
Prints the NV bitmap image 1 (double-size)
]
Prints the NV bitmap image 2 (double-size)
^
Prints the NV bitmap image 3 (double-size)
_
Prints the NV bitmap image 4 (double-size)
`
Prints the NV bitmap image 5 (double-size)

BIXOLON SRP-350plusIII Specifications

General

Type	POS printer
Character size	24 x 24 mm
Print technology	Direct thermal
Maximum resolution	180 x 180 DPI
Product color	Gray
Maximum roll diameter	83 mm
Supported paper width	80/58 mm
Maximum printing width	72 mm
Printing media thickness	50 - 80 µm
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 45 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
USB port	Yes
Serial interface type	RS-232
USB 2.0 ports quantity	1
Connectivity technology	Wired
Wi-Fi	No
Built-in barcodes	1D, 2D, CODABAR (NW-7), Code 39, Code 93, Code-128 Codabar Library, Data Matrix, EAN13, EAN8, ITF, ITF-14, ITF-25, Micro QR Code, QR Code, UPC-A, UPC-E
Autocutter durability	1.8 million cuts
Harmonized System (HS) code	84433210

Weight and Dimensions

Depth	146 mm
Width	145 mm
Height	204 mm
