SRP-382
Rev. 1.00
- 38 -
5-7 Bidirectional Communication
1) Open the Printer Properties window for the corresponding OS.
2) Click Ports tab.
Because bidirectional support is disabled by default, it is necessary to tick Enable
bidirectional support to get status from the printer. Sample codes contained in the CD
can help you get more status information than the status information that OS supplies as
standard way. This windows driver supports only one-on-one communication between the
printer and host (typically a PC).
Printer status that OS support
Printer status that OS does not support
- ONLINE/OFFLINE
- COVER OPEN/CLOSE
- PAPER EMPTY
- NEAR END PAPER
- CASH DRAWER OPEN/CLOSE

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the BIXOLON SRP-382 and is the answer not in the manual?

BIXOLON SRP-382 Specifications

General IconGeneral
TypePOS printer
Print technologyDirect thermal
Product colorBlack
BluetoothYes
USB 2.0 ports quantity1
Connectivity technologyWired
Ethernet LANNo
Maximum roll diameter83 mm
Supported paper width80/58 mm
Maximum printing width72 mm
Printing media thickness0.062 - 0.075 µm
Size (imperial)3 \
Sustainability certificatesENERGY STAR
AC input voltage100-240 V
Power source typeAC
AC input frequency50-60 Hz
Flash memory64 MB
RAM capacity0.128 GB
Built-in barcodes1D, 2D
Autocutter durability3 million cuts
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)10 - 80 %
Mobile operating systems supportedAndroid, iOS
Weight and Dimensions IconWeight and Dimensions
Depth148 mm
Width147 mm
Height200 mm
