SRP-382
Rev. 1.00
- 44 -
7-1-3 Barcode Printing
The following example code explains how to print the barcode (JAN8 (EAN)).
'Print Bar Code.
Printer.FontSize = 18
Printer.FontName = "Barcode4"
Printer.Print "1234567"
Printer.EndDoc
The following example code explains how to print the 2D barcode (PDF417).
'Print Two-dimensional Codes.
Printer.FontSize = 8.5
Printer.FontName = "2D-Code1"
Printer.Print "Print Test PDF417"
Printer.EndDoc

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the BIXOLON SRP-382 and is the answer not in the manual?

BIXOLON SRP-382 Specifications

General IconGeneral
TypePOS printer
Print technologyDirect thermal
Product colorBlack
BluetoothYes
USB 2.0 ports quantity1
Connectivity technologyWired
Ethernet LANNo
Maximum roll diameter83 mm
Supported paper width80/58 mm
Maximum printing width72 mm
Printing media thickness0.062 - 0.075 µm
Size (imperial)3 \
Sustainability certificatesENERGY STAR
AC input voltage100-240 V
Power source typeAC
AC input frequency50-60 Hz
Flash memory64 MB
RAM capacity0.128 GB
Built-in barcodes1D, 2D
Autocutter durability3 million cuts
Storage temperature (T-T)-20 - 60 °C
Operating temperature (T-T)0 - 40 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)10 - 80 %
Mobile operating systems supportedAndroid, iOS
Weight and Dimensions IconWeight and Dimensions
Depth148 mm
Width147 mm
Height200 mm
