BIXOLON SRP-382 User Manual

SRP-382
Rev. 1.00
- 43 -
7. Use of Windows Driver
7-1 Use of Visual Basic
This section contains example codes to control the printer using Windows driver with
Visual Basic. Sample programs are included in the CD.
7-1-1 Windows Driver Selection
The following example code explains how to select “BIXOLON SRP-382” Windows driver.
For Each prnPrinter In Printers
If prnPrinter.DeviceName = “BIXOLON SRP-382” Then
Set Printer = prnPrinter
Exit For
End If
Next
7-1-2 Text Printing
The following example code explains how to print texts using Windows Fonts and Device
Fonts.
„Print in Windows font
Printer.FontSize = 9
Printer.FontName = “Arial”
Printer.Print “Arial Test”
„Print in printer font
Printer.FontSize = 8.5
Printer.FontName = “FontA1x1”
Printer.Print “FontA1x1 Font”
Printer.EndDoc

BIXOLON SRP-382 Specifications

General

Type	POS printer
Print technology	Direct thermal
Product color	Black
Bluetooth	Yes
USB 2.0 ports quantity	1
Connectivity technology	Wired
Ethernet LAN	No
Maximum roll diameter	83 mm
Supported paper width	80/58 mm
Maximum printing width	72 mm
Printing media thickness	0.062 - 0.075 µm
Size (imperial)	3 \
Sustainability certificates	ENERGY STAR
AC input voltage	100-240 V
Power source type	AC
AC input frequency	50-60 Hz
Flash memory	64 MB
RAM capacity	0.128 GB
Built-in barcodes	1D, 2D
Autocutter durability	3 million cuts
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Mobile operating systems supported	Android, iOS

Weight and Dimensions

Depth	148 mm
Width	147 mm
Height	200 mm
