72
(relative to 100 kHz, 5
Vpp)
Cross Talk
< -70 dBc
Offset Range (DC)
Channel 1: ± 5 V into 50 Ω
± 10 V into open circuit
Channel 2: ± 1.5 V into 50 Ω
± 3 V into open circuit
Offset Resolution
Up to 4 digits
Offset Accuracy
± ( |Offset setting value| * 1% + 3 mV)
Output Impedance
50 Ω (typical)
Output Protection
Short-circuit protection
Waveform Characteristics
Harmonic Distortion
DC – 1 MHz, < - 60 dBc
1 MHz – 5 MHz, < -53 dBc
5 MHz – 25 MHz, < - 35 dBc
25 MHz – 50 MHz, < -32 dBc
Total Harmonic
Distortion
DC – 20 kHz at 1 Vpp, < 0.2 %
Spurious (non-
harmonic)
DC – 1 MHz, < -70 dBc
1 MHz – 10 MHz , < -70 dBc + 6 dB/spectrum phase
Phase Noise
10 kHz offset, - 108 dBc/Hz (typical)
Rise/Fall Time (Square)
< 12 ns (10 % - 90 %) at full amplitude into 50 Ω
Variable Duty Cycle
(Square)
20% - 80% to 10 MHz
40% - 60% to 20 MHz
50% > 20 MHz
Asymmetry (50 % duty
cycle)
1% of period + 20 ns (typical,1 kHz, 1 Vp-p))
Jitter square)
0.1 % of period (typical, 1 kHz, 1 Vp-p)
Ramp Symmetry
0 % - 100 %
Linearity (Triangle,
ramp at 1 kHz, 1 Vp-p,
100% symmetry)
< 0.1 % of peak output (typical)
Pulse
Pulse Width
16 ns minimum,
8 ns resolution
Rise/Fall Time
7 ns (typical) at 1 kHz, 1 Vpp from 10 % – 90%
Duty Cycle
0.1 % resolution
Overshoot
< 5 %
Jitter (pk-pk)
8 ns
Burst
Waveform
Sine, Square, Ramp, Pulse, Arbitrary (except DC)
Type
Cycle (1 – 50,000 cycles), Infinite, Gated
Start/Stop Phase
0 ° – 360 °
Internal Period
1 µs – 500 s
Gated Source
External Trigger
