73
Trigger Source
Internal, External, Manual
Phase Offset
Range
0 ° – 360 °
Resolution
0.1 °
Trigger Characteristics
Trigger Input
Input Level
TTL compatible
Slope
Rising or Falling, selectable
Pulse Width
> 100 ns
Input Impedance
> 5 kΩ, DC coupling
Maximum
Frequency
1 MHz
Input Latency
< 300 ns
Trigger Output
Voltage Level
TTL compatible
Pulse Width
> 400 ns
Output Impedance
50 Ω
Maximum
Frequency
1 MHz
Modulation Characteristics
Amplitude Modulation
Carrier
Sine, Square, Ramp, Arbitrary (except DC)
Source
Internal, External
Modulation
Waveform
Sine, Square, Ramp, Noise, Arbitrary (2 mHz – 20 kHz)
Modulation Depth
0 % - 120 %
Frequency Modulation
Carrier
Sine, Square, Ramp, Arbitrary (except DC)
Source
Internal, External
Modulation
Waveform
Sine, Square, Ramp, Noise, Arbitrary (2 mHz – 20 kHz)
Frequency
Deviation
0 – 0.5*bandwidth, 10 µHz resolution
FSK
Carrier
Sine, Square, Ramp, Arbitrary (except DC)
Source
Internal, External
Modulation
Waveform
50 % duty cycle square waveform (2 mHz – 50 kHz)
ASK
Carrier
Sine, Square, Ramp, Arbitrary (except DC)
Source
Internal, External
Modulation
Waveform
50 % duty cycle square waveform (2 mHz – 50 kHz)
DSB-AM
Carrier
Sine, Square, Ramp, Arbitrary (except DC)
Source
Internal, External
