BK Precision 9110 User Manual

15
9110
100W Multi Range 60V/5A DC Power Supply
CV CC
OVP OCP
V
A
B
C
D
Lock Preset
OFF
Shift
A
V
A
Quick Start
Set Voltage
Set Voltage
Press the
D V/A
key to turn the “V”
9110
100W Multi Range 60V/5A DC Power Supply
CV CC
indicator on. Now you can set the voltage
value. Use the cursor keys
A B
OVP OCP
to highlight the desired digit then adjust
its value with the knob.
In this example the cursor is set to
A
B
C
D
Lock
Preset
OFF
Shift
position
B
and the voltage value can be
adjusted in 1V increments.
cursor in B position
Set Current
Press the
D V/A
key to turn on the “A”
indicator. Now you can set the current
value. Use cursors
A B
to highlight the desired digit then adjust
its value with the knob.
In this example the cursor is set to
position
A
and the current value can be
adjusted in 1A increments.
cursor in A position
Set Current
Turn output On/Off
9110
Press
On/Off
to toggle the output between
100W Multi Range 60V/5A DC Power Supply
CV CC
ON or OFF. The OFF LED is lit when
the output is turned off. Each time you
OVP OCP
press the
On/Off
key, the display will blink
A
B
C
D
Lock Preset
for 3 seconds and the set value for Volts
and Amps is displayed. Afterwards, if
the instrument has been set to ON, the
actual output values for voltage and
current are displayed.
OFF
Shift
Output OFF Indicator
