Cursor Position and Step Size
Cursor position
Voltage step size
Current step size
A
1A
B
1V
0.1A
C
0.1V
0.01A
D
0.01V
0.001A
Check the Set Voltage and Set Current Value
The power supply usually displays the actual voltage and current value. Press
Shift
twice to check the set value for voltage and current. The display will blink for 3
seconds while displaying the set values.
Key Lock Function
This function locks the keyboard to prevent unintended modification of power
supply settings. Press
Shift
(Shift LED will be lit), followed by the
C
(Lock)
key. Now the keys and the knob are locked and the Lock LED is lit. Press the
Shift key followed by the Lock key again to disable the Lock function.
OVP Function
Press
Shift
then press and hold the
9110
100W Multi Range 60V/5A DC Power Supply
CV CC
D V/A
(Setup) key for 3 seconds.
OVP OCP
Afterwards the LCD will display OVP
and you can adjust the OVP value using
A
B
C
D
V
Lock
Preset
the cursor keys
A
B
knob.
and the
OFF
Shift
OCP Function
After the OVP value is set, press
C
to
OVP Value
enter OCP mode. Use the cursor keys
9110
A B
OCP value.
Note
and the knob to set the
100W Multi Range 60V/5A DC Power Supply
A
B
C
D
CV CC
OVP OCP
Lock
Preset
The output of the power supply will
automatically turn off if the OVP and
OCP value are less than the actual
voltage and current value.
OCP Value
OFF
Shift
