18
Storing Voltage/Current sets
Store up to four sets of voltage/current values to the group number assigned in the previous
paragraph. Press
Shift
followed by the
A
(Save) key. All 4 cursor LEDs A B C D
will blink simultaneously. Press one of the
A
B
C
D
V/A
keys to assign one of the 4 available memory location within this group. Proceed
accordingly for the other 3 sets.
Preset Mode
Press
Shift
followed by the
B
(Preset) key. The Preset LED will turn on to indicate
that the Preset mode is now active. The most recently selected group number will
automatically be activated. To activate the preset values from a different group, follow
the instructions in “Selecting a group number”. Press one of the
A
B
C
D
V/A
keys to recall one of the corresponding stored Volt/Amp sets assigned in the previous
step. In this mode, the cursor functionality of the A,B,C, D keys is disabled. To exit this
mode, press
Shift
then
B
(Preset).
Trouble shooting hints
If the output is disabled
1. Check if the voltage and current values are zero. If set to zero, set the voltage and
current value again.
2. Check if the OFF indicator is lit. If so, press the
On/Off
key to turn the output on.
3. Check if the OCP or OVP indicator is lit. If so, set the OVP or OCP value
appropriately.
If keys are disabled
Check the Lock LED. If it is lit, disable the Lock function.
