1. From the LIST SET menu, select LIST STATE and press .

2. There are two options that can be selected using the rotary knob:

OFF – Disable List mode

ON – Enable List mode

3. Select the desired option and press to save the change.

4. To exit the menu at any time, press twice.

5. When List mode is enabled, the will be lit until triggered.

6. To run a loaded list file, set the Trigger mode (Refer to “Configure Trigger Source”

section) and manually or remotely trigger the power supply. The button will

blink while running a list file.

Note: Voltage and current settings cannot be changed while List mode is enabled.

Load List File

1. From the LIST SET menu, select LIST LOAD and press .

2. Use keys or rotary knob to select one of the stored list files between FILE0 –

FILE9 and press .

3. To exit the menu at any time, press twice.

Edit List File

To edit a list, follow the procedure below.

1. From the LIST SET menu, select LIST EDIT and press .

2. Use keys or rotary knob to select unit of time (Sec or Min) for steps.

3. VSET will be displayed. Use the numeric keypad to enter the step’s voltage value and

press to confirm.

4. ISET will be displayed. Use the numeric keypad to enter the step’s current value and

press to confirm.

5. As specified previously, SEC or MIN will be displayed. Use the numeric keypad to enter

the step’s time value and press to confirm.

BK Precision 9200B Series User Manual
