Developer Information
34
The IDENTIFY border will temporarily override any other border setting in effect.
The BORDER property can be used to programmatically set the soft Tally colored borders to one of the
primary colors: RED, GREEN, BLUE, WHITE or NONE. This setting can be overridden by the electrical Tally
signals at the DB-9 input on the device itself. For example, to set the soft Tally to green:
MONITOR B:↵
Border: green↵
↵
The hard wired tally will always override the soft tally. The full state report will always show the current valid
border.
SmartScope Settings
On SmartScope Duo, each monitor can be set to display a different scope. The values for activating specific
scopes are mapped as follows:
AudioDbfs
AudioDbvu
Histogram
ParadeRGB
ParadeYUV
Picture (This is the same as Video Monitor)
Vector100
Vector75
WaveformLuma
MONITOR A:↵
ScopeMode: Picture↵
↵
In the example above, Monitor A has been set as a video monitor.
