Bluewater Pro - Install drain water connection; Connect water purifier

14
Complete User manual
Install drain water connection
The flushed water goes through the drain water tubing to the drain water outlet. This tubing
can be a maximum of four meters long. The minimum internal diameter is 13 mm.
Figure 16.
×1 ×2
1 2
X
Y
Install drain water connection
Minimum Maximum
X 50 mm (2”) 500 mm (20”)
Y 50 mm (2”) 500 mm (20”)
Connect water purifier
Do not connect the clean water tubing to other drinking water equipment before
Pro has been flushed.
19
mm
(3/4”)
2
31
UK US ZH EU
5 64 7
19
mm
(3/4”)
Figure 17. Connect water purifier
