Bluewater Pro - TECHNICAL INFORMATION

26
Complete User manual
TECHNICAL INFORMATION
Technical data
Size W×H×D Weight Power supply
earthed
Power Purified water flow
rate
Sound level
Pro 400B-HR
230V
225×466×460 mm 29 kg 230V, 50-60 Hz 530 W 3.1 ±0.5 l/min
< 60 dB(A)
120V
8.9×18.3×18.1” 64 lbs 120V, 60 Hz 6 Amps 0.8 ± 0.13 gal/min
Pro 400C-HF
230V
225×466×460 mm 29 kg 230V, 50-60 Hz 530 W 3.5 ±0.5 l/min
< 60 dB(A)
120V
8.9×18.3×18.1” 64 lbs 120V, 60 Hz 6 Amps 0.9 ± 0.13 gal/min
Pro 400C-HR
230V
225×466×460 mm 29 kg 230V, 50-60 Hz 530 W 3.1 ±0.5 l/min
< 60 dB(A)
120V
8.9×18.3×18.1” 64 lbs 120V, 60 Hz 6 Amps 0.8 ± 0.13 gal/min
Pro 400BC-HR
230V
225×466×460 mm 29 kg 230V, 50-60 Hz 530 W 3.1 ±0.5 l/min
< 60 dB(A)
120V
8.9×18.3×18.1” 64 lbs 120V, 60 Hz 6 Amps 0.8 ± 0.13 gal/min
Pro 400CV-HR
230V
225×466×470 mm 29 kg 230V, 50-60 Hz 530 W 3.0 ±0.5 l/min
< 60 dB(A)
120V
8.9×18.3×18.5” 64 lbs 120V, 60 Hz 6 Amps 0.8 ± 0.13 gal/min
Pro 400BCV-HR
230V
225×466×470 mm 29 kg 230V, 50-60 Hz 530 W 3.0 ±0.5 l/min
< 60 dB(A)
120V
8.9×18.3×18.5” 64 lbs 120V, 60 Hz 6 Amps 0.8 ± 0.13 gal/min
Pro 600C-HF
230V
225×466×460 mm 29 kg 230V 50-60 Hz 720 W 5.2 ±0.5 l/min < 60 dB(A)
Pro 600CV-HR
230V
225×466×470 mm 29 kg 230V 50-60 Hz 720 W 4.5 ±0.5 l/min < 60 dB(A)
Recovery [%] Rejection [%] On/Off
[bar (psi)]
Membrane
6310C
Prefilter Operation sequence
(production/flush)
[minutes]
Pro 400B-HR 50-60 97-99 0.5/2 (7.3/29) High rejection Particle
Granulated carbon
Max 15
Pro 400C-HF 60-70 95-99 3/4.5 (44/65) High flow Particle
Granulated carbon
15/2
Pro 400C-HR 50-60 97-99 3/4.5 (44/65) High rejection Particle
Granulated carbon
15/2
Pro 400BC-HR 50-60 97-99 0.5/2 (7/29) High rejection Particle
Granulated carbon
15/2
Pro 400CV-HR 50-60 97-99 3/4.5 (44/65) High rejection Particle
Granulated carbon
15/2
Pro 400BCV-HR 50-60 97-99 0.5/2 (7/29) High rejection Particle
Granulated carbon
15/2
Pro 600C-HF 60-70 95-99 3/4.5 (44/65) High flow Carbon block 15/2
Pro 600CV-HR 60-70 97-99 3/4.5 (44/65) High rejection Carbon block 15/2
