Detailed assembly instructions
32
• Install the adaptor on the Shimano Di2 battery.
Enlarge the adaptor and slide onto the battery
Screw the adaptor into the seatpost foam core
untill fush
• Screw in the seatpost internal foam core using a 21mm flat wrench. Tighten lightly untill the adap-
tor head is flush to the seat post foam core.
