Detailed assembly instructions
58
Rear light installation
• Install the BMC Rear Light lower bracket into the seat tube rear pocket.
• Push it untill it sits on the machined stopper.
Push in the back of seat tube to the stopper
2 1 Nm
• Tighten to 1 Nm using a hex 2mm wrench.
• Install the seat post rubber seal and the seat post as described earlier in “Frame seatpost clamp
installation”, page 35.
