Detailed assembly instructions
31
Roadmachine Owners Manual
Electronic wires installation
Shimano Di2
WARNING: Please always refer to the latest Shimano product information for your groupset. The
following information is a guide with basic principles.
Battery:
BT-DN300
Front Derailleur:
EW-SD300, 700mm
Rear Derailleur:
EW-SD300, 1400mm
Recommended wire lengths:
Location Part code Length
Front Derailleur EW-SD300 700mm
Rear Derailleur EW-SD300 1 400mm
• Install the different electronic wires into the frame.
INFORMATION: It helps a lot to use a cable routing guiding tool like the Park Tool IR-1.2 Internal
Cable Routing Kit
