Detailed assembly instructions
57
Roadmachine Owners Manual
Seat tube bottle cage
3 3 Nm
• Install the BMC Seat tube bottle cage or the bottle cage of your choice.
• Tighten the 2x M5x12 bolts to 3 Nm using a hex 3mm wrench.
Top tube storage
The Roadmachine is equipped with top tube threads to allow the mounting of top tube storage.
The top tube storage threads are covered by plugs.
WARNING: Do not exceed a torque of more than 5Nm with the top tube storage bolts.
WARNING: When not used, top tube mounts must be covered with the provided blind plug to
avoid water and dust to enter the mounts and contaminate the inside of the frame and the threads..
Remove plugs
to access top tube mounts
