Detailed assembly instructions
56
Storage cover with bottle cage
• To install, align the knob with the arrow oriented to the top and slide verticaly the cover into the
frame opening.
INFORMATION: Align the cover and frame keys to fit the cover into the frame.
WARNING: The cover is designed to fit the frame and protect the inside from most of the dust
and water. However, it’s not waterproof..
Slide vertically to fit
Storage cover
Slide vertically to fit
INFORMATION: As the cover will fit perfectly flush with the down tube, it will be difficult to take
it off.
Use the bottle cage mounts to attach a bottle cage (or just a single bolt) to help grab the cover and
pull it out.
WARNING: The cover is designed to fit the frame and protect the inside from most of the dust
and water. However, it’s not waterproof.
