BMC Roadmachine

Detailed assembly instructions
61
Roadmachine Owners Manual
D-Fender
Roadmachine seatposts are compatible with the D-fender for seat-
posts using M6 hardware (saddle clamp bolts).
The compatible D-fender is identified with an M6 engraving located
next to the clamping bolt.
M6
Remove protection bolt & clip on the D-fender
• Remove the protection headless bolt prior to installing the D-fender.
• Clip on the D-fender by inserting the back of the seatpost head into the D-fender cavity.
3 3 Nm
Threadlocker
• Apply threadlocker and install the M5x12 countersunck bolt provided with the D-fender.
• Tighten to 3 Nm using a hex 3mm wrench.
