BMC timemachine road - Seat Clamp and Seat Post Installation

Seat clamp & seat post Installation
1. Apply grease on the seat post clamp wedges as well as on the seat post clamp outer surface.
Do not put grease on the seat post contact surface.
2. Assemble the seat post clamp (1) and insert it into the frame (2).
3. For Di2 shifting install the Di2 integrated Battery into the seat post.
4. Apply carbone friction paste on the lower part of the seat post as well as on the inside of the seat tube.
5. Insert the seat post into the seat tube.
6. Install the saddle clamping hardware (N°1).
7. Tighten the seat post clamp bolt to 5Nm max (3).
8. Install the rubber plug (N°3) to close the gap on the top tube.
Description Part N°
1 Saddle clamp kit 212482
2 Seat post clamp kit 212483
3 Rubber plug 212484
4 Seat post “team red” 212478
Seat post “flame” 212479
Seat post “shark” 212480
Seat post “white” 212481
3
2
grease
5Nm
1
2 3
9 / 10
