TANKS SCREEN
Users can control the water pump, electric, gas
heaters and tank heaters from the water screen,
if applicable.
The Water screen displays the levels of fresh,
gray and black water tanks. Levels shown are:
FULL
2/3 FULL
1/3 FULL
EMPTY
LEVELING AND MOTORS SCREENS
The Leveling and Motors Screens control Slide-outs, Awnings, Landing Legs
and Jacks. It contains controls for certain Leveling Systems installed in the RV.
Before operating any motors, ensure the area is free from
obstacles and other hazards. Please ensure that any persons
near the RV are not in any danger from moving parts.
WARNING
NOTE: Not all leveling systems are compatible with the JAYCOMMAND System.
FIGURE 14: Tanks Screen
18
