BMW E36 - ELECTRONIC TRANSMISSION CONTROL (EGS A4 S 270 R) GEAR SELECTOR SWITCH

ELECTRONIC TRANSMISSION CONTROL (EGS A4S 270R)
1 TWO–DOOR
5 TWO–DOOR
9
31 31 3131
BMWBMWBMW
GEAR SELECTOR SWITCH
04/99
2460.2Ć
1998
03
P90
FRONT POWER
DISTRIBUTION BOX
F28
5A
F26
10A
L4 L3 L2 L1
A8500
TRANSMISSION
CONTROL MODULE
(EGS)
9 37 8 36 X8500
86 74
.5 BR/WS .5 BL/WS .5 BR/SW .5 BL/SW
X5113
1 BL/GE
S3
AUTOMATIC
TRANSMISSION
RANGE SWITCH
0) OFF (LOW)
1) ON (HIGH)
2) CLOSED IN
REVERSE
2 X5115
L4 L3 L2 L1
R
E46
LEFT LUGGAGE
COMPARTMENT
LIGHT ASSEMBLY
6
X319
4
X191
21 20 19 X6918
A8
CRUISE CONTROL
MODULE
(TEMPOMAT)
X22
.35 BR/SW .5 BR/SW
1 BL/GE
.5 BR/WS .5 BL/WS .5 BR/SW .5 BL/SW
.5 BR/SW
L1 L2 L3 L4
P
R
N
D
3
2
1
1101
1000
1110
0001
0011
1011
0010
4 X13
GROUND
DISTRIBUTION
0670.4
H27
LEFT BACK UP
LIGHT
X319
FUSE DETAILS
0670.3
01
X13006
010101 02
16 X1001712
EGS A4S 270R
E82
TRANSMISSION
POSITION INDICA-
TOR LIGHT
2
X1193
1
.5 GR/RT
X1193
GROUND
DISTRIBUTION
0670.4
X10012
LIGHT SWITCH
DETAILS
6300.0
58g
X1019
.5 GR/RT
FUSE DETAILS
0670.3
A836
ELECTRONIC
IMMOBILIZER
CONTROL MODULE
(EWS II)
X1659
5
