DRIVER’S SEAT
04/99
5200.0Ć
1998
00
5200.0 POWER SEATS
P90
FRONT POWER
DISTRIBUTION BOX
F40
30A
X10018
20
5
X603
FUSE DETAILS
0670.3
S51
DRIVER’S SEAT,
SEAT CONTROL
SWITCH
3) SEAT HEIGHT
SWITCH
0) OFF
1) UP
2) DOWN
5) SEATBACK
SWITCH
0) OFF
1) FRONT
2) BACK
6) SEAT CUSHION
TILT SWITCH
0) OFF
1) UP
2) DOWN
7) SEAT
POSITION
SWITCH
0) OFF
1) FRONT
2) BACK
2121 21212121 2
12 1
53 7
M53
DRIVER’S SEAT-
BACK RECLINER
MOTOR
6
1
1.5 GN/VI
2 X729
1.5 SW/VI
X60312 10 7 8 3 4 12
M52
DRIVER’S SEAT
HEIGHT MOTOR
1
1.5 BL/GR
2 X728
1.5 VI/GR
M51
DRIVER’S SEAT
MOVEMENT
MOTOR
1
1 GN/GE
2 X726
1 SW/GE
M50
DRIVER’S SEAT
CUSHION TILT
MOTOR
2
1 VI/RT
1 X727
1 BL/RT
X13006
GROUND
DISTRIBUTION
0670.4
6
GN SW BL VI GN SW VI BL
00 00 00 00
