BMW E36 - Page 132

04/99
2460.2Ć
1998
07
A8500
TRANSMISSION
CONTROL MODULE
(EGS)
9
32
7
.5 BL
4
3
.5 VI
33
2
.5 GN
30
1
.5 OR
5
6
.5 GR
21
.5 SW
2
14
.5 SW
X8500
8
1
.5 RT
.5 GE .75 RT
NS
31 31 31 31 31 31 31
W8516
SHIELD UP TO
10mm BEFORE
ELECTRONIC
TRANSMISSION
OUTPUT SHAFT
SPEED SENSOR
(EGS)
X8516
X8516
Y8505y
TRANSMISSION VALVE
UNIT
1) SOLENOID VALVE 1
2) SOLENOID VALVE 2
3) SOLENOID VALVE 3
6) HYDRAULIC
PRESSURE REG-
ULATOR
7) TORQUE
CONVERTER
CLUTCH SOLENOID
VALVE
8) OIL TEMPERATURE
SENSOR
9) SPEED SENSOR
.5 TR
.75 BR
X8073
15
31
14 2
X8505
4
1 12 9 11 X8505
616
