BMW E36 - ZKE CENTRAL LOCKING (ZV) OUTPUT DETAILS

BMW
OUTPUT DETAILS
04/99
5126.0Ć
1998
00
5126.0 ZKE CENTRAL LOCKING (ZV)
F7
5A
X1001514
M12
DRIVER’S DOOR
LOCK MOTOR
1) LOCK
2) UNLOCK
1 2 3 X660
FUSE DETAILS
0670.3
F35
25A
X10018
10
FUSE DETAILS
0670.3
A104
BODY
ELECTRONICS
CONTROL MODULE
(ZKE IV)
.5 WS/
SW
6
12
5
X660
.5 WS/
GN
P90
FRONT POWER
DISTRIBUTION BOX
F7
5A
X10015
14
FUSE DETAILS
0670.3
10 X13252
2
M13
PASSENGER’S
DOOR LOCK
MOTOR
1) LOCK
2) UNLOCK
123 X641
6
12
5 X641
4
1 9 X13252
.5 WS/GN .5 WS/SW
15
1.5 BL/GR
17 X25716
1.5 SW 1.5 WS
1.5 BL/GR
1.5 SW
1.5 WS
X453
2.5 BL/GR
X462
X455
1.5 WS 1.5 SW
1.5 BL/GR
16 17 15
1.5 SW 1.5 BL/
GR
1.5 WS
2.5 SW 2.5 WS
1
2
(PARTIAL)
(PARTIAL)
(PARTIAL)
X25612
.5 RT/
GN
12
.5 RT/GN
2
1
4
M16
GAS FILLER LOCK
MOTOR
1 X312
1.5 BL/GR
X453 (PARTIAL)
X312
1.5 SW
2
M107
GLOVE BOX LOCK
MOTOR
1 X13263
1.5 SW
X13263
1.5 BL/GR
2
5126.0-01
