BMW E36 - Page 17

BM
BMW
BMWBMW
04/99
0140.0Ć
1998
02
4 RT
15
4 GN
13
.5 GN/WS
5
2.5 SW/GE 2.5 VI
42
DETAILS ABOUT
COMPONENT OR
OPERATION
”R” IS ENERGIZED
IN ACCY, RUN, OR
START
76 8
2 X33
CONTACT RELAY
RELAY WITH
RESISTOR
ACROSS WINDING
TERMINAL NUMBER THREE POLE,
FOUR POSITION
SWITCH
COMPONENT NUMBER
S2
IGNITION SWITCH
0) OFF
1) ACCESSORY
2) RUN
3) START
TERMINAL NUMBER DESCRIPTION
50 VOLTAGE: IGNITION
SWITCH IN START
VOLTAGE: SUPPLIED
AT ALL TIMES
VOLTAGE: IGNITION
SWITCH IN RUN OR
START
30
15
15I
50 R
30
INDICATES THAT
FUSE 9 IS SUPPLIED
WITH POWER AT ALL
TIMES
CONTACT RELAY
WITH TWO OUTPUTS
CHANGEOVER
RELAY WITH TWO
OUTPUTS
TERMINAL NUMBER DESCRIPTION
30 RELAY INPUT
RELAY OUTPUT
(WINDING)
RELAY INPUT
(WINDING)
RELAY OUTPUT
(ENERGIZED)
RELAY OUTPUT
(AT REST)
85
86
87
87a
30 86
87 87 85
30 86
87 8587a
TERMINAL NUMBER DESCRIPTION
VOLTAGE: IGNITION
SWITCH IN RUN
VOLTAGE: IGNITION
SWITCH IN ACCES-
SORY, RUN OR START
15I
R
GROUND31
POWER STATUS DESCRIPTION
VOLTAGE: SUP-
PLIED AT ALL TIMES
VOLTAGE: IGNITION
SWITCH IN RUN OR
START
VOLTAGE: IGNITION
SWITCH IN ACCES-
SORY, RUN OR START
30 86
87 85
30
86
87 85
NAME OF COMPONENT
F9
15A
2
1
0
3
2
1
0
3
2
1
0
3
SYMBOLS
