BMW E36 - Pin Assignments (X13156)

5430.1Ća
BMW
BMW
BMW
1998
Pin Assignments
04/99
BMW
E = Input, A = Output, M = Ground
A = X13156 10 Pins, black
B = X13157 6 Pins, black
C = X13159 26 Pins, black
D = X11390 12 Pins, black
X13156
Pin Type Description/Function Connection
1 Not used
2 Not used
3 E/A Activate engine Windscreen cowl panel locking
(automatic convertible top)
4 E/A Control signal Convertible top motor
5 E/A Control signal Convertible top storage lid motor
6 M Ground Ground
7 E/A Activate engine Windscreen cowl panel locking
(automatic convertible top)
8 E/A Control signal Convertible top motor
9 E/A Control signal Convertible top storage lid motor
10 E Plus supply 12V Fuse 49
X13157
Pin Type Description/Function Connection
1 A Plus supply Position sensor
(convertible top storage lid motor)
2 E Position signal Convertible top position micro switch
3 E Position signal Convertible top end position micro switch
(semi-automatic convertible top)
4 E Component ground Position sensor
(convertible top storage lid motor)
5 E Position signal Convertible top position micro switch
6 E Control signal Position sensor
(convertible top storage lid motor)
