BMW E36 - Page 187

BMW
04/99
5430.1Ć
1998
01
ELECTRICAL CONVERTIBLE TOP
A96
CONVERTIBLE TOP
CONTROL MODULE
5
2
.35 GN/SW
X13157
8
2
X13006
GROUND
DISTRIBUTION
0670.4
4
.35 GR/RT
X13230
GROUND
DISTRIBUTION
0670.4
1 X13143
X13143
S196
REAR WINDOW
BLOWER MICRO
SWITCH
1) CONVERTIBLE
TOP RAISED
UP
2) CONVERTIBLE
TOP DOWN
3
.35 BR/GE
REAR WINDOW
DEFOGGER/
ANTENNA
6424.0
X13159
12
12
1 X13079
2
.35 BL/GE
3
X13079
X13157
S164
CONVERTIBLE TOP
END–POSITION
MICRO SWITCH
1) TOP TENSION
RELIEVED
2) TOP FULLY
EXTENDED
.35 BR/OR
5
.35 SW/GN
3
.35 SW/BR
2 1 X13045
1 14
LIGHT SWITCH
DETAILS
6300.0
S143
CONVERTIBLE TOP
ACTUATING
SWITCH
0) OFF
1) CLOSE
2) OPEN
1
S165
CONVERTIBLE TOP
POSITION MICRO
SWITCH
0) LATCH NOT
SET
1) LATCH LOCKED
2) LATCH
UNLOCKED
1
.35 BR/OR
2
2
4
3 X13152
.35 BR/OR
X13152
.35 SW/BL .35 SW/GN
.35 BR/OR.35 BR/OR
12
0
00
6
.35 GR/RT
X13045
17
X13159
SEMI–AUTOMATIC
CONVERTIBLE TOP
AUTOMATIC
CONVERTIBLE TOP
