10
Features description
The Wallbox Pro is a charging station designed to efficiently charge electric vehicles batteries. It has
been designed to provide energy management features and to integrate domestic energy generation.
It can be connected to a network with internet access to provide Charge Detail Records and Event
Reports, if any.
Installation with Power Meter Installation without Power Meter
Domestic energy Switchboard
Car charging power supply Undervoltage remote tripping unit
(optional)
Grid Ethernet (optional)
RS-485 Network connection Smart Home
System (optional)
Power Meter Wallbox Pro
The Wallbox Pro is a 7.4 kW charging station with an attached cable with a Type 2 connector. A
power meter (only with Part No. 61 90 2 288 283) is delivered with the Wallbox Pro to enable energy
monitoring and energy management.
The driver is informed of the charging status and charging information by a 7-inch touch screen and
by light strips. The touch screen and light strips are activated either by the proximity sensor or when a
person touches the Wallbox Pro screen.
The touch screen provides information on the on-going charge as well as statistics on previous
charges. The homeowner can select to protect access to the Wallbox Pro interface via a username and
PIN code or he can select unprotected access, hence having "plug and charge" behaviour.
The load management feature when activated enables Wallbox Pro to automatically determine the
maximum power it can allocate to the car without tripping the house main breaker, hence avoiding a
power outage. In addition, the contract power can be optimized.
