Pin Assignments (M Versions)
01/01
Z3
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionSignalType
37 A P_EVZ5 Activate valve Cyl. 5 fuel injection valve
38 A P_EVZ6 Activate valve Cyl. 6 fuel injection valve
39 E F_OLN Oil level/temperature signal Thermal oil level switch
40 Not used
41 Not used
42 A T_TEV Activate valve Evaporative emission valve
43 A T_NWA_S1 Activate valve Variable camshaft control valve
(outlet) – retard
44 A T_NWA_F1 Activate valve Variable camshaft control valve
(outlet) – advance
45 A S_DMTL–LED Tire pressure warning lamp control Instrument cluster
46 A T_LLFSS CLOSE signal Idle speed control valve
47 A T_LLFSO OPEN signal Idle speed control valve
48 Not used
49 Not used
50 A T_NWE_S1 Activate valve Variable camshaft control valve
(inlet) – retard
51 A S_SSP Activate valve Solenoid valve, sucking jet pump
52 Not used
X60004
Pin Type Signal Description/Function Connection
1 A 61 Battery charge indicator Instrument cluster
2 Not used
3 A S_SLP Activate relay Secondary air pump relay
4 E ELUE Signal, auxiliary fan ON High speed relay
5 Not used
6 E S_50 Signal start Fuse 15
7 M M_FW1 Ground Pedal position sensor
8 E A_FW1 Signal, pedal position 1 Pedal position sensor
9 A U_FW1 Voltage supply Pedal position sensor
10 Not used
