Pin Assignments (M Versions)
01/01
Z3
E = Input, A = Output, M = Ground
Pin ConnectionDescription/FunctionSignalType
11 A OELD Signal, oil pressure Instrument cluster
12 M M_FW2 Ground Pedal position sensor
13 E A_FW2 Signal, pedal position 2 Pedal position sensor
14 A U_FW2 Voltage supply Pedal position sensor
15 Not used
16 Not used
17 A TD Crankshaft RPM speed signal (TD) Electronic immobilizer control
module (EWS III)
18 Not used
19 E RFL Reversing light signal Reversing light switch
20 A TOG Signal oil level Thermal oil level switch
21 Not used
22 E DFAHR Speed signal right rear Dynamic stability control unit
23 Not used
24 E KL 54 ON Brake signal Brake light switch
25 Not used
26 E 15A26 Terminal 15 Fuse 26
27 E MFL Cruise control signal Cruise control interface
28 E A_S_LDPV Leakage diagnosis Leakage diagnosis pump
29 A KOREL Activate relay Compressor control relay
30 E A_T_LDP Leakage diagnosis Leakage diagnosis pump
31 Not used
32 E/A TXDII TXD diagnosis data link Data link connector
33 E S_DWA Drive-away protection signal (code) Electronic immobilizer control
module (EWS III)
34 E S_BLTS Signal test Brake light switch
35 M 31 Ground Cruise control interface
36 E/A CAN+ CAN-bus High Splice, CAN-bus High
37 E/A CAN– CAN-bus Low Splice, CAN-bus Low
38 Not used
39 Not used
