BMW Z3(E36/7) - Page 148

BM
BMW
BMWBMW
Z3
SLIP CONTROL (ABS/ASC)
06/00
3450.1
2001
Ć02
1
2 6 5 20 19
22 23 X1170
1 2X114 2 1 X142 2 1X113 2 1 X143
B2
LEFT FRONT SPEED
SENSOR – ABS
B4
LEFT REAR SPEED
SENSOR – ABS
B1
RIGHT FRONT SPEED
SENSOR – ABS
B3
RIGHT REAR SPEED
SENSOR – ABS
LEFT FRONT
PULSE WHEEL
A52
SLIP CONTROL
MODULE
(ABS/ASC)
LEFT REAR
PULSE WHEEL
RIGHT FRONT
PULSE WHEEL
RIGHT REAR
PULSE WHEEL
.5 BR .5
BR/
RT
.5 BL .5
BR
.5 GE .5
BR
.5 GE/SW .5
GE/
BR
3 3
X170 X170
31
313131
31 31
