OUTPUT DETAILS
01/01
5126.0Ć
2001
04
ZKE CENTRAL LOCKING (ZV)
X1001514
M12
DRIVER’S DOOR
LOCK MOTOR
1) LOCK
2) UNLOCK
1 2 3 X660
FUSE DETAILS
0670.3
X1001810
FUSE DETAILS
0670.3
A104
BODY
ELECTRONICS
CONTROL MODULE
(ZKE IV)
.5 WS/SW
6
1
5
X6604
.5 WS/GN
P90
FRONT POWER
DISTRIBUTION BOX
X10015
14
FUSE DETAILS
0670.3
10 X13252
1
M13
PASSENGER’S
DOOR LOCK
MOTOR
1) LOCK
2) UNLOCK
1
23 X641
6
5 X6414
29
.5 WS/GN .5 WS/SW
15
1.5 BL/GR
17
X257
16
1.5 SW 1.5 WS
1.5 BL/GR
1.5 SW
1.5 WS
X462
2.5 SW
X453
X455
16 17 X25615
1.5 SW 1.5 BL/
GR
1.5 WS
2.5 BL/GR 2.5 WS
2
12
.5 RT/GN
12
.5 RT/
GN
F7
5A
F35
25A
F7
5A
12 12
12
X13252
1.5 WS
1.5 SW
1.5 BL/GR
M COUPE
.35 WS/SW
.35 WS/GN
14 X25713
2 X3121
.75 BL/GR
3 X104702
.75 SW
.75 BL/GR.75 SW
M16
GAS FILLER LOCK
MOTOR
