BMW Z3(E36/7) - Page 177

114
15 X132532
01/01
5126.0Ć
2001
05
A104
BODY
ELECTRONICS
CONTROL MODULE
(ZKE IV)
.35 WS/GN
.5 WS/SW
14 X256
.5 WS/GN
13
.35 WS/BR .35 WS/GR.35 WS/SW .35 WS/GN
31 31 31 31
4 2 X1376
X13766
K70
CENTRAL LOCKING
LUGGAGE
COMPARTMENT
LID MOTOR RELAY
(ZV)
8
2
12
1
X1236
1.5 RT/WS
S117
LUGGAGE COMPARTMENT
LID LOCKING SWITCH
1) UNLOCK
2) LOCK
X1775
.35 WS/GN
GROUND DISTRIBUTION
0670.4
X166
GROUND DISTRIBUTION
0670.4
X13006
2
1
X1775
.35 WS/GN/GE
86 30
8785
POWER
DISTRIBUTION
0670.2
X10285
M17
LUGGAGE
COMPARTMENT
LOCK MOTOR
X10285
G7512
B+ JUNCTION
POINT
30
X1978
F103
80A
