SLIP CONTROL (ABS/ASC)
04/99
3450.1Ć
1998
06
5
P90
FRONT POWER
DISTRIBUTION BOX
F10
30A
.5 GR/RT
F21
5A
21
S6
ASC SWITCH
1) OFF
2) ON
A52
SLIP CONTROL
MODULE
(ABS/ASC)
21
20 X1171
2.5 SW/BR/GE
+
X100942
M93
AUXILIARY
THROTTLE
POSITION MOTOR
(ADS)
1 X10094
2.5 SW/GN/GE
–
A52
SLIP CONTROL
MODULE
(ABS/ASC)
X521
4
6
X18170
27
X1171
51
2
X521
LIGHT SWITCH
DETAILS
6300.0
58g
.5 BL/VI
TD
X1171
41
X1047
INSTRUMENT
CLUSTER
6211.0
.5 SW
.5 SW
X2020
A6000
ENGINE CONTROL
MODULE (DME)
X6000
.5 SW
X8015
.5 SW
TD
X1001520
FUSE DETAILS
0670.3
FUSE DETAILS
0670.3
GROUND
DISTRIBUTION
0670.4
36
X100172
1 X6002
D100
DATA LINK
CONNECTOR
.5 SW
BM
BMW
BMWBMW
Z3
Z3 ROADSTER 6–CYLINDER
