BMW Z3 E37 1998 - Page 241

paragon.myvnc.com
BM
BMW
BMWBMW
Z3
COMPRESSOR CONTROL AND WATER SUPPLY
INTEGRATED HEATING– AND CLIMATE CONTROL
04/99
6450.6Ć
1998
07
F16
5A
30
87
F39
7.5A
18 X10018
FUSE DETAILS
0670.3
.75 SW
2
1
2
.5 SW/BL
5 X51
Y2
AIR CONDITIONING
COMPRESSOR
1) NORMAL
TEMPERATURE
2) HIGH
TEMPERATURE
K19
COMPRESSOR
CONTROL RELAY
FUSE DETAILS
0670.3
6
4 X51
12 X10016
X10241
86
85
15
4 X20
74 X6000
A6000
ENGINE CONTROL
MODULE (DME)
.5 SW/BL
1
P90
FRONT POWER
DISTRIBUTION BOX
31
M ROADSTER
