FUSES 21 AND 22
04/99
0670.3Ć
1998
05
FUSE DETAILS
P90
FRONT POWER
DISTRIBUTION BOX
S8
LIGHT SWITCH
2 X503
4
.5 GN/GE
6300.0
2
.5 GN/BL/GE
6312.0
S6
ASC SWITCH
35
3450.1
.5 GN/BL/
GE
K10
ABS RELAY
4 X54
3450.1
.5 GN/BL/
GE
A52
SLIP CONTROL
MODULE
(ABS/ASC)
3450.1
.5 GN/BL/GE
S6
ASC SWITCH
5 X521
3450.1
.5 GN/BL/GE
.5 GN/BL/GE .5 GN/BL/GE
X1163
X1163
5 X521
.5 GN/BL/GE
X10017
F21
5A
F22
5A
A52
SLIP CONTROL
MODULE
(ABS/ASC)
X1171
Z3 ROADSTER
6–CYLINDER 4–CYLINDER
3450.1
4 X1170
K10
ABS RELAY
3450.0
.5 GN/BL/GE
A7
SLIP CONTROL
MODULE (ABS)
8X11
3450.0
.5 GN/BL/GE
X1163
4 X54
19
.5 GN/BL/GE
.5 GN/BL/GE
M ROADSTER
WITH ABS
