CONNECTING THE CABLE LEADS
Prior to connecting your cable leads we recommend that you read the section
of the manual called IMPORTANT GUIDELINES FOR EQUIPMENT CARE.
The BODYSTAT
1500 unit has two main
cable leads. Each lead is to be inserted to
the connectors at the rear of the unit. The
red dot on the lead wire should be lined
up with the red dot on the device.
DO NOT insert the leadwire into the device
without aligning the red dots. Non-
alignment will damage the socket
mounted on the PCB. Such damage is not
covered by our warranty.
The two main blue cable leads each contain a RED and BLACK crocodile clip.
These can be attached to either the foot or the hand, they are therefore,
interchangeable.
